PAD CALCULATION
Software: BV001-PadDesign.xlsm & BV001DesignPad.dll
BS EN 1992-1-1:2004 - Eurocode 2, BS EN 1997-1:2004 - Eurocode 7 ...
Introduction:
Pads are common structural parts in civil and industrial constructions
Pad software is design calculator for single foots , including the following features:
• Calculating the pad bearing capacity according to ground data from the Soil Investigation Report
• Calculating foundation layout.
• Structural calculating reinforced concrete pad structure, including monoclinic single foundation
• Estimating settlement of pads.
• Including material data of Vietnamese building codes
The software uses reaction data from the results of structural analysis of other software (such as Etab, Sap2000 ...)
• Automation selects the most unfavorable internal force - does not use envelope combinations
• Automation of pad structural calculation.
• Automate settle estimation of pads as specified by the engineer
Applicable for all types of single-footing foundation (center column), single-eccentric foundation (column at pad edge or column at pad corner)
How to use:
- Calculated data
• Copy the results of the reactions from the internal analysis software (such as SAP, ETAB ...) to the corresponding data pages.
• Enter geological data
- Automatic calculation
• The most unfavorable internal force is exerted on the respective foots in the case
• Arrangement of pads on plan, classifying foundation and quantity of each type
• Identify the most unfavorable foundations in each pad type
• Calculate the common pads. Calculation of eccentricity takes into account the background force redistribution
• Estimation of adverse pad settlement
- Optimizing texture
• Easy to change the foot sizes to optimize the pad layout
• Easily change the bar diameters and number of steel bars to optimize the structure of each foundation
- Report & Print calculation results
Related software:
- Structural analysis programs (SAP2000, ETab ...)
